News 1 : Setup Single Particle-ICPMS using Nu AttoM017

News 2 : Age Cytometry to decode the evolutional

                 sequence of the Earth

Simultaneous detection of 206Pb and 207Pb has been made by dual-Daly ion counters equipped on multiple collector-ICP-mass spectrometer (MC-ICPMS).  Long term stability, evaluated by the relative changes in the measured signal intensity for over the 10 hours period, was better than 0.4%, which was significantly smaller than that achieved by the conventional ion counting technique using the electron multipliers.  The resulting higher gain stability could be due to clear difference in the peak heights between the noise components and the signals from collectors.  After the correction for the counting loss due to the collector dead time, the Daly ion counter is capable to accept the signal intensities as high as 107 cps.  This indicates that the crossover of the measurable range can exceed at least three orders of magnitude between the Daly ion counters (100 – 107 cps) and the Faraday collectors (103 – 1010 cps), suggestive of easier cross calibration between the collectors.  With the present dual-Daly ion counters, in-situ 207Pb/206Pb ratio measurements have been made on glass standards (NIST SRM 614)  by means of the laser ablation sampling technique.

Imaging for U-Th-Pb isotopes were measured by ArF Excimer laser ablation (ESI, NWR193) coupled with quadrupole-based ICP-mass spectrometer (Thermo Fisher Scientific,  iCAPQc).  Images were obtained by the repeated analysis of line profiling, and the resulting signal intensity profile were vidualised by iQuant2 software, specially designed for the LA-ICPMS by the imaging team at TITech and Kyoto University.  This software is available on request.  Please contact any contributors of this presentation.  Several unique features can be derived with the latest version (iQuant2+), such as chemical analysis, bird-view monitoring, as well as user friendly interface.

iQuant2 software is free of charge : contact Tak Hirata for further information.
